[EOL] USB Module with MAX3421E
Product Status Notice This product is EOL (End of Life). Please order the new version: Module USB v1.2
Description
Module USB is a USB driver module in the M5Stack stackable module series. It integrates the MAX3421E chip, which can add USB host or peripheral functionality to any system with SPI. If you want to add a standard USB interface to your device, this Module USB will be the perfect solution.
Note Core2 and CoreS3 are not compatible with this product. If used with Core2, the EN pin of M5-Bus needs to be cut off to disconnect the EN connection.
Features
- 1x Module USB standard port
- Uses SPI communication protocol
- 10x GPIO pin expansion
- Expansion pins: 3v3, 5v, GND
Includes
- 1 x Module USB
Applications
- USB host/peripheral
Specifications
| Specification | Parameter |
|---|---|
| Net Weight | 13g |
| Gross Weight | 25g |
| Product Size | 54.2 x 54.2 x 12.8mm |
| Package Size | 60 x 57 x 17mm |
